CONTENTS

INTRODUCTION 6
Basics of Power Factor Correction – Calculation of Required Capacitor Power
and Common Methods – Influence of Harmonics, Harmonic Filtering –
Capacitors in High Frequency Filters

OUR RANGE OF FACTORY MATCHED KEY COMPONENTS 13

POWER CAPACITORS 14

INTERNAL CONSTRUCTION 16
Dielectric – Impregnants - MKPg 275

SAFE OPERATION 17
Self-Healing Dielectric – Protection Against Accidental Contact –
Protection Against Overload

TERMINATION DESIGNS 19
CAPAGRIP™ - MKP(D)

DEFINITIONS AND SELECTION CRITERIA 23
Voltage Ratings – Test Voltages – Rated Power – Current Ratings –
Temperature Categories – Lifetime Statements

GENERAL TECHNICAL DATA 25

DATA CHARTS MKPg 275 3PH GAS-FILLED
400 … 440 V 26
400 … 480 V 27
400 … 525 V 28
525 V 28
400 … 525 V 29
690 … 760 V 30
690 … 800 V 30

DATA CHARTS MKP UHD™ 280 3PH OIL-FILLED
400 … 580 V 31

DATA CHARTS MKP(D) 276 3PH OIL-FILLED
400 … 480 V 32
400 … 525 V 32

DATA CHARTS MKP-1 276 1PH OIL-FILLED
400 … 480 V 33
400 … 525 V 33
