E62 - 3HF
High Frequency
1200...1400V AC
C N R S L e R th I ma× Î I S D × L 1 Design m order no. pcs / bo×
1
(µF) (mΩ) (nH) (K/W) (A) (kA) (kA) (mm) Maßbild (kg) Bestell-Nr. Stk / Bo×
2580V U BB 2010V 50Hz AC / 2s U BG 4800V 50Hz AC / 2s
U N 1200V AC U rms 850V U S
3 × 8 3 × 1 110 4.7 3 × 39 1 3 75 × 164 S4 0.8 E62.M16-802S40 5 / FB8
3 × 25 3 × 0.4 110 3.0 3 × 56 3.2 9.6 116 × 164 S4 1.8 E62.R16-253S40 3 / FB12
3 × 37.5 3 × 0.55 130 2.0 3 × 56 2.6 7.8 116 × 245 S4 2.8 E62.R24-373S40 3 / FB12 S4
3 × 41.5 3 × 0.6 130 2.0 3 × 100 2.6 7.8 116 × 245 MB 2.8 E62.R24-413MB0 3 / FB12
3 × 55.7 3 × 0.5 130 1.7 3 × 100 3.6 10.8 136 × 245 MB 3.8 E62.S24-563MB0 2 / FB12
3000V U BB 2370V 50Hz AC / 2s U BG 4800V 50Hz AC / 2s
U N 1400V AC U rms 1000V U S
3 × 10 3 × 0.5 110 3.0 3 × 100 1.8 5.4 116 × 164 MB 1.8 E62.R16-103MB0 3 / FB12
3 × 33 3 × 0.55 130 1.7 3 × 100 2.8 8.4 136 × 245 MB 3.8 E62.S24-333MB0 2 / FB12
3 × 42 3 × 0.6 145 1.8 3 × 56 2.5 7.5 116 × 280 S4 3.1 E62.R28-423S40 3 / FB10
Other values and dimensions available on request. DATA CHARTS_DATENTABELLEN_E62 - 3HF
