E62 - 3HF
High Frequency
750...1130V AC
C N R S L e R th I ma× Î I S D × L 1 Design m order no. pcs / bo×
1
(µF) (mΩ) (nH) (K/W) (A) (kA) (kA) (mm) Maßbild (kg) Bestell-Nr. Stk / Bo×
1610V U BB 1250V 50Hz AC / 2s U BG 3600V 50Hz AC / 2s
U N 750V AC U rms 530V U S
3 × 16 3 × 0.9 100 5.4 3 × 39 0.6 1.8 65 × 164 Z3 0.6 E62.L16-163Z30 10 / FB8
3 × 23 3 × 0.5 110 4.7 3 × 39 0.85 2.5 75 × 164 S4 0.8 E62.M16-233S40 5 / FB8
S4/Z3 3 × 30 3 × 0.7 120 4.1 3 × 56 1.1 3.3 85 × 164 S4 1 E62.N16-303S40 5 / FB8
3 × 38.4 3 × 0.7 125 3.7 3 × 56 1.4 4.2 95 × 164 S4 1.2 E62.P16-383S40 3 / FB8
3 × 48 3 × 0.5 130 3.5 3 × 56 1.7 5.1 100 × 164 S4 1.4 E62.Q16-483S40 3 / FB12
3 × 100 3 × 0.55 130 2 3 × 56 2 6 116 × 245 S4 2.8 E62.R24-104S40 3 / FB12
3 × 100 3 × 0.55 130 2 3 × 100 2 6 116 × 245 MB 2.8 E62.R24-104MB0 3 / FB12
1830V U BB 1420V 50Hz AC / 2s U BG 4800V 50Hz AC / 2s
U N 850V AC U rms 600V U S
3 × 9 3 × 0.8 100 5.8 3 × 39 0.8 2.4 60 × 164 Z3 0.5 E62.K16-902Z30 10 / FB8
3 × 11 3 × 0.9 100 5.4 3 × 39 1 3 65 × 164 Z3 0.6 E62.L16-113Z30 10 / FB8
3 × 12 3 × 0.9 100 5.4 3 × 39 1.1 3.3 65 × 164 Z3 0.6 E62.L16-123Z30 10 / FB8
3 × 14 3 × 0.5 120 4.7 3 × 39 1.2 3.6 75 × 164 S4 0.8 E62.M16-143S40 5 / FB8
3 × 19 3 × 0.5 120 4.1 3 × 56 1.7 5.1 85 × 164 S4 1 E62.N16-193S40 5 / FB8
3 × 25 3 × 0.6 120 3.7 3 × 56 2.2 6.6 95 × 164 S4 1.2 E62.P16-253S40 3 / FB8
3 × 30 3 × 0.7 110 3.7 3 × 56 2.6 7.8 95 × 164 S4 1.2 E62.P16-303S40 3 / FB8
3 × 37.5 3 × 0.45 110 3 3 × 56 3.2 9.6 116 × 164 S4 1.9 E62.R16-373S40 3 / FB8
3 × 72.5 3 × 0.5 130 2 3 × 56 3.6 10.8 116 × 245 S4 2.8 E62.R24-723S40 3 / FB12
3 × 100 3 × 0.5 130 1.7 3 × 100 5 15 136 × 245 MB 3.8 E62.S24-104MB0 2 / FB12
2320V U BB 1800V 50Hz AC / 2s U BG 4800V 50Hz AC / 2s
U N 1080V AC U rms 760V U S
3 × 11 3 × 1 110 4.7 3 × 39 1.2 3.6 75 × 164 S4 0.8 E62.M16-113S40 5 / FB8
3 × 18.4 3 × 0.5 125 3.7 3 × 56 1.9 5.7 95 × 164 S4 1.2 E62.P16-183S40 3 / FB8
3 × 22 3 × 0.5 130 3.1 3 × 56 2 6 95 × 196 S4 1.5 E62.P19-223S40 3 / FB12
DATA CHARTS_DATENTABELLEN_E62 - 3HF
3 × 27.6 3 × 0.4 120 3 3 × 56 3.1 9.3 116 × 164 S4 1.8 E62.R16-283S40 3 / FB8
3 × 55.7 3 × 0.4 130 2.1 3 × 56 5 15 136 × 196 S4 3 E62.S19-563S40 2 / FB12
3 × 55.7 3 × 0.5 130 2 3 × 100 3.1 9.3 116 × 245 MB 2.8 E62.R24-563MB0 2 / FB12
3 × 75 3 × 0.5 130 1.7 3 × 100 4.4 13.2 136 × 245 MB 3.8 E62.S24-753MB0 2 / FB12
2430V U BB 1890V 50Hz AC / 2s U BG 4800V 50Hz AC / 2s
U N 1130V AC U rms 800V U S
3 × 33.4 3 × 0.55 130 2.5 3 × 56 1.9 5.7 95 × 245 S4 1.9 E62.P24-333S40 3 / FB12
3 × 46 3 × 0.55 130 2 3 × 56 2.8 8.3 116 × 245 S4 2.8 E62.R24-463S40 3 / FB12
3 × 49 3 × 0.5 130 2 3 × 56 2.9 8.7 116 × 245 S4 2.8 E62.R24-493S40 3 / FB12
Other values and dimensions available on request.
