P. 14
E50.***PK16™ for latest edition and updates
DC check www.powercapacitors.info
600V
–
Niederinduktive Zwischenkreiskondensatoren CQC low low
Low-inductance DC Capacitors
Standards......................................... IEC 61071, optional IEC 61881 C tolerance Toleranz ..........................................±10%; optional ±5%
N
UL 810 tanδ 0 .................................................................... 2 × 10 -4
can Gehäuse.....................................aluminium/plastic, (UL94: VO) limit temperatures Grenztemperaturen
Ѳ ...................................................................-40°C
min
mounting position........................optional Ѳ max (HOTSPOT) .........................................................+85°C 1
Einbaulage beliebig
filling material.............................solid, based on vegetable oil, non-PCB storing temperature Lagertemperatur....................-40°C ... +85°C
Füllmittel ausgehärtet, auf Pflanzenölbasis, PCB-frei Life time Lebensdauer ........................................> 200 000 h
internal protection.......................none Failure rate Ausfallrate......................................50 FIT 2
interne Sicherung keine 1 endurance type test_Lebensdauertest: Ø116 @80°C, Ø136 @75°C
fire load Brandlast.......................40 MJ/kg 2 reference service life_Referenzbetriebsdauer 100000 h, Ѳ HOTSPOT ≤70°C
C R R I Î I E L D × L Design m order no. pcs / Box
N S th max S N e 1 1
(µF) (m) (K/W) (A) (kA) (kA) (Ws) (nH) (mm) Maßbild (kg) Bestell-Nr. Stk / Box
100V U S 900V U TT 900V DC U TC 3300V AC/2s
U N 600V DC U r
465 2.6 5.8 20 1.9 5.7 84 50 67 × 114 N4 0.4 E50.L11-474N40 10/FB2
555 1 6.7 40 3.8 11.4 100 30 85 × 85 NT 0.5 E50.N85-564NT0 10/FB12
NT ø85/116
680 1.1 6 40 3.8 11.5 122 40 85 × 95 NT 0.6 E50.N95-684NT0 10/FB12
780 1.6 5.2 30 3.7 11 140 60 85 × 110 NT 0.7 E50.N11-784NT0 10/FB10
NT ø136 930 1.4 4.7 40 3.8 11.5 167 35 85 × 120 NT 0.7 E50.N12-934NT0 10/FB10
DATA CHARTS_DATENTABELLEN_E50.*** PK16™
1000 1.8 4.2 35 3.7 11 180 55 85 × 136 NT 0.8 E50.N13-105NT0 10/FB15
1110 0.84 3.8 80 7.6 22.9 200 40 85 × 150 NT 0.9 E50.N15-115NT1 5/FB8
1430 2.3 3.1 35 3.7 11.1 257 60 85 × 181 NT 1.2 E50.N18-145NT0 5/FB8
N5
1450 0.82 3.1 80 10 29.9 261 45 100 × 155 N5 1.3 E50.Q15-155N57 3/FB8
2000 1.4 2.3 60 7.4 22 360 60 85 × 252 NT 1.6 E50.N25-205NT0 5/FB10
N4
2070 0.62 2.5 90 14.2 42.7 373 40 116 × 155 NT 1.8 E50.R15-215NT0 3/FB8
2530 0.66 2.1 90 14.2 42.6 455 50 116 × 180 NT 2.1 E50.R18-255NT0 3/FB12
4000 0.58 1.3 120 20 60 720 70 116 × 295 NT 3.2 E50.R29-405NT0 3/FB15
4275 0.55 1.5 120 29 88 770 60 136 × 220 NT 3.4 E50.S22-435NT0 2/FB12
5060 0.72 1.1 120 28.4 85.2 911 85 116 × 340 NT 3.9 E50.R34-515NT0 3/FB15
7000 0.66 1 120 29 87 1260 70 136 × 335 NT 5.2 E50.S33-705NT0 2/FB15
14 Other values and dimensions available on request.
Andere Werte und Abmessungen auf Anfrage erhältlich.
