E51
AC/DC for latest edition and updates
3500...4950V AC / 4950...21000V DC check www.powercapacitors.info

Axial Low-inductance AC/DC-Capacitors
Niederinduktive Wechsel-/Gleichspannungskondensatoren LO W LO W
in axialer Bauform

Standards ...................................IEC 61071, optional IEC 61881 C tolerance Toleranz ..............................................±10% (optional ±5%)
N
tanδ ........................................................................2 ××10 -4
0
can Gehäuse ...............................plastic Kunststoff (UL94: VO)
mounting position Einbaulage ...optional beliebig operating temperatures Grenztemperaturen
filling material ...........................solid, based on vegetable oil, non-PCB Θ ... Θ ..........................................................-25 ... +70°C
max
min
Füllmittel ....................................ausgehärtet, auf Pflanzenölbasis, PCB-frei Θ HOTSPOT .................................................................≤ 70°C
Internal protection .....................none storing temperature Lagertemperatur ........................-40 ... +85°C
Interne Sicherung .....................keine
fire load Brandlast .....................40 MJ/kg Failure rate Ausfallrate .........................................100 FIT
(reference interval_Referenzintervall 100000 h, Θ HOTSPOT ≤ 70°C)

U AC U DC C N U rms U S U TT R S R th I max Î I S L e D ×× L 1 m order no. pcs_Stk
N
N
1
(V) (V) (µF) (V) (V) (V) (mΩ) (K/W) (A) (kA) (kA) (nH) (mm) (kg) Bestell-Nr. / Box
U N 3500V ... 3700V AC U rms 2500V ... 2600 V
3500 4950 0.15 2500 5250 9900 (DC) 2.2 9.7 20 0.4 1.1 60 64 × 120 0.4 E51.L12-151R20 10/FB0
3500 5000 0.22 2500 9000 9000 (DC) 4.8 9.7 20 0.7 2.1 60 64 × 120 0.4 E51.L12-221R20 10/FB0
3500 5100 0.33 2500 9000 9000 (DC) 3 9.7 20 0.98 2.94 60 64 × 120 0.5 E51.L12-331R20 10/FB0
3500 5100 0.5 2500 9000 9000 (DC) 5.6 9.7 20 1 3 60 64 × 120 0.4 E51.L12-501R20 10/FB0
3500 5200 0.68 2500 7500 7500 (DC) 4.9 3.2 40 0.76 2.28 15 64 × 130 0.4 E51.L13-681R20 10/FB0
3500 5500 1.25 2500 9000 9900 (DC) 2.2 6.4 45 1.4 4.2 60 90 × 130 0.9 E51.P13-132R20 10/FB12
3500 6000 1.5 2500 9000 9000 (DC) 2.2 6.4 45 1.5 4.4 60 90 × 130 0.9 E51.P13-152R20 10/FB12
3550 6500 0.73 2500 7800 8410 (DC) 4.6 3.2 20 0.86 2.58 20 64 × 130 0.4 E51.L13-731R20 10/FB0
3650 7000 0.1 2575 7500 8635 (DC) 7.4 5.3 20 0.4 1.3 15 64 × 78 0.3 E51.L78-101R20 10/FB2
3700 7500 1.5 2600 5600 8000 (AC) 3.6 3 15 2.2 6.6 100 90 × 285 1.9 E51.P28-152R20 5/FB12
U N 4000V ... 4950V AC U rms 2825V ... 3500 V

4000 8900 0.3 2825 6000 5500 (DC) 10.4 4.2 5 0.78 2.34 100 64 × 275 0.9 E51.L27-301R70 10/FB12
9
8900
0.22
64 × 130
E51.L13-221R20
60
4550 10000 0.33 3200 10920 10920 (DC) 8.9 1.7 15 0.34 1.02 100 116 × 130 0.4 E51.R13-202R20 10/FB0
DATA CHARTS_DATENTABELLEN_E51 4750 15000 0.5 2200 10000 7000 (AC) 5.2 2.3 10 1.15 3.45 100 140 × 200 2.4 E51.P35-102R20 10/FB7
9
20
6.7
10920 10920 (DC)
0.46 1.38
64 × 130
60
0.4
10/FB0
E51.L13-331R20
4550
3200
1.4
3200
4550
55
13800
7.2
2
2.4
60
1.3
6/FB12
10920 10920 (DC)
7050
90 × 275
10
2.2
15000
6.6
5/FB12
1
E51.P27-102R20
1.8
3200
4700
3.8
3
6880 (AC)
4
5/FB15
1
80
1.5
90 × 355
E51.S20-382R20
2/FB8
3.2
4920
2.7
3480
4.8
1.3
15
15000 3.75
12300 12300 (DC)
14.4
7.1
64 × 165
5
E51.L16-251R21
3500
0.6
9000 11710 (DC)
4950
15560 0.25
100
15
E51.L27-501R70
21000
3500
2.5
10000
10/FB12
8500 (AC)
4950
64 × 275
6
10
100
4.2
1
0.9
10 Other values and dimensions available on request
Andere Werte und Abmessungen auf Anfrage erhältlich
